Product Summary

The EL5427CLE is a 2.5MHz 4-, 8-, 10- and 12-channel rail-to-rail buffer. The EL5427CLE is low power, high voltage rail-to-rail input/output buffers designed for use in reference voltage buffering applications in small LCD displays. It is available in quad EL5427CLE topologies. The buffer of the EL5427CLE features a -3dB bandwidth of 2.5MHz and operates from just 133μA per buffer. The EL5427CLE also features a continuous output drive capability of 30mA (sink and source).

Parametrics

EL5427CLE absolute maximum ratings: (1)Supply Voltage Between VS+ and VS-: +18V; (2)Input Voltage: VS- -0.5V, VS +0.5V; (3)Maximum Continuous Output Current: 30mA; (4)ESD Voltage: 2kV; (5)Maximum Die Temperature: +125℃; (6)Storage Temperature: -65℃ to +150℃; (7)Operating Temperature: -40℃ to +85℃.

Features

EL5427CLE features: (1)2.5MHz -3dB bandwidth; (2)Supply voltage = 4.5V to 16.5V; (3)Low supply current (per buffer) = 133μA; (4)High slew rate = 2.2V/μs; (5)Rail-to-rail input/output swing; (6)Ultra-small packages; (7)Pb-free plus anneal available (RoHS compliant).

Diagrams

EL5427CLE block diagram
