Product Summary

The DAC712U is a complete 16-bit resolution D/A converter with 16 bits of monotonicity over temperature. The DAC712U has a precision +10V temperature compensated voltage reference, ±10V output amplifier and 16-bit port bus interface. The digital interface of the DAC712U is fast, 60ns minimum write pulse width, is double-buffered and has a CLEAR function that resets the analog output to bipolar zero. GAIN and OFFSET adjustment inputs of the DAC712U are arranged so that they can be easily trimmed by external D/A converters as well as by potentiometers.

Parametrics

DAC712U absolute maximum ratings: (1)+VCC to COMMON: 0V, +17V; (2)–VCC to COMMON: 0V, –17V; (3)+VCC to –VCC: 34V; (4)Digital Inputs to COMMON: –1V to +VCC –0.7V; (5)External Voltage Applied to BPO and Range Resistors: ±VCC; (6)VREF OUT: Indefinite Short to COMMON; (7)VOUT: Indefinite Short to COMMON; (8)Power Dissipation: 750mW; (9)Storage Temperature: –60℃ to +150℃; (10)Lead Temperature (soldering, 10s): +300℃.

Features

DAC712U features: (1)High-speed 16-bit paralledoublebuffered interface; (2)Voltage output: ±10V; (3)13-, 14-, and 15-bit linearity grades; (4)16-bit monotonic over temperature (L grade); (5)Power dissipation: 600mW max; (6)Gain and offset adjust: Convenient for Auto-CaD/A Converters; (7)28-lead dip and soic packages.

Diagrams

DAC712U block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DAC712UB
DAC712UB

Texas Instruments

DAC (D/A Converters) 16-Bit Digital-to- Converter

Data Sheet

0-1: $16.22
1-10: $15.26
10-25: $14.30
25-50: $14.03
DAC712UBG4
DAC712UBG4

Texas Instruments

DAC (D/A Converters) 16B DAC

Data Sheet

0-1: $15.47
1-10: $14.56
10-25: $13.64
25-50: $13.38
DAC712UG4
DAC712UG4

Texas Instruments

DAC (D/A Converters) 16-Bit Digital-to- Converter

Data Sheet

0-1: $13.31
1-10: $12.53
10-25: $11.74
25-50: $11.51
DAC712UL
DAC712UL

Texas Instruments

DAC (D/A Converters) 16-Bit Digital-to- Converter

Data Sheet

0-1: $19.16
1-10: $18.03
10-25: $16.90
25-50: $16.57
DAC712ULG4
DAC712ULG4

Texas Instruments

DAC (D/A Converters) 16-Bit Digital-to- Converter

Data Sheet

0-1: $18.27
1-10: $17.19
10-25: $16.11
25-50: $15.80
DAC712UKG4
DAC712UKG4

Texas Instruments

DAC (D/A Converters) 16-Bit Digital-to- Converter

Data Sheet

0-1: $14.28
1-10: $13.43
10-25: $12.59
25-50: $12.35
DAC712UK
DAC712UK

Texas Instruments

DAC (D/A Converters) 16-Bit Digital-to- Converter

Data Sheet

0-1: $14.96
1-10: $14.08
10-25: $13.19
25-50: $12.94
DAC712U
DAC712U

Texas Instruments

DAC (D/A Converters) 16-Bit Digital-to- Converter

Data Sheet

0-1: $13.99
1-10: $13.16
10-25: $12.33
25-50: $12.09
