Product Summary

The C8051F132 is a mixed signal ISP flash MCU family. The C8051F132 is fully integrated mixed-signal System-on-a-Chip MCUs with 64 digital I/O pins (100-pin TQFP package) or 32 digital I/O pins.

Parametrics

C8051F132 absolute maximum ratings: (1)Ambient temperature under bias: -55 125 ℃; (2)Storage Temperature: -65 150 ℃; (3)Voltage on any Pin (except VDD and Port I/O) with; (4)respect to DGND: -0.3 VDD + 0.3V; (5)Voltage on any Port I/O Pin or /RST with respect to DGND: -0.3 5.8 V; (6)Voltage on VDD with respect to DGND: -0.3 4.2 V; (7)Maximum Total current through VDD, AV+, DGND, and AGND: 800 mA; (8)Maximum output current sunk by any Port pin: 100 mA.

Features

C8051F132 features: (1)Programmable throughout up to 100ksps; (2)Up to 8 external inputs: Programmable as single ended or differential; (3)Programmable amplifier gain: 16, 8, 4, 2, 1, 0.5; (4)Data dependent widowed interrupt generator; (5)Built in temperature sensor.

Diagrams

C8051F132 blcok diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
C8051F132
C8051F132

Silicon Labs

8-bit Microcontrollers (MCU) 128kB 100MIPS 8448B RAM

Data Sheet

Negotiable
C8051F132-GQ
C8051F132-GQ

Silicon Labs

8-bit Microcontrollers (MCU) 100MIPS 64KB 10ADC 100P MCU

Data Sheet

0-1: $6.46
1-25: $6.22
25-100: $5.98
100-1000: $5.56
C8051F132-GQR
C8051F132-GQR

Silicon Labs

8-bit Microcontrollers (MCU) 100MIPS 64KB 10ADC Tape and Reel

Data Sheet

0-250: $6.45
250-500: $6.26
500-1000: $6.07
C8051F132R
C8051F132R

Silicon Labs

8-bit Microcontrollers (MCU) 128kB 100MIPS 8448B RAM

Data Sheet

Negotiable
