Product Summary

The CYV15G0404DXB-BGXC is a independent clock quad HOTLink II transceiver with reclocker. The CYV15G0404DXB-BGXC Independent Clock Quad HOTLink II. Transceiver is a point-to-point or point-to-multipoint communications building block enabling the transfer of data over a variety of high speed serial links including SMPTE 292, SMPTE 259, and DVB-ASI video applications. The signaling rate can be anywhere in the range of 195 to 1500 MBaud for each serial link. Each channel operates independently with its own reference clock allowing different rates. Each transmit channel of the CYV15G0404DXB-BGXC accepts parallel characters in an input register, encodes each character for transport, and then converts it to serial data.

Parametrics

CYV15G0404DXB-BGXC absolute maximum ratings: (1)Storage Temperature: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: –55℃ to +125℃; (3)Supply Voltage to Ground Potential: –0.5V to +3.8V; (4)DC Voltage Applied to LVTTL Outputs in High-Z State: –0.5V to VCC + 0.5V; (5)Output Current into LVTTL Outputs (LOW): 60 mA; (6)DC Input Voltage: –0.5V to VCC + 0.5V; (7)Static Discharge Voltage > 2000 V; (8)Latch-up Current> 200 mA.

Features

CYV15G0404DXB-BGXC features: (1)Synchronous LVTTL parallel interface; (2)JTAG boundary scan; (3)Built In Self Test (BIST) for at-speed link testing; (4)Link quality indicator by channel. Analog signal detect. Digital signal detect; (5)Low power 3W at 3.3V typical; (6)Single 3.3V supply; (7)256 ball thermally enhanced BGA; (8)0.25μ BiCMOS technology; (9)JTAG device ID 0C811069x.

Diagrams

CYV15G0404DXB-BGXC System Connections

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
CYV15G0404DXB-BGXC
CYV15G0404DXB-BGXC

Cypress Semiconductor

Telecom Line Management ICs 3.3V QUAD HOTLINK II TRANS W/RECLOCKER

Data Sheet

Negotiable
