Product Summary

The AD389KD is a high accuracy, adjustment free track-and-hold amplifer. The device is designed for high resolution data acquisition applications. The fast acquisition tiem and low aperture jitter make the AD389KD suitable for use with fast A/D converters to digitize signals up to 40KHz. The device is complete with an internal hold capacitor and it incorporates a compensation network which minimizes the sample to hold charge offset. The typical applications of the AD389KD inlcude sampled data systems, peak hold functions, storbed measurement systems and simultaneous sampling converter systems.

Parametrics

AD389KD absolute maximum ratings: (1)voltage range: ±10V min; (2)overvoltage, no damage: ±15V ,ax; (3)impedance: 3000Ω; (4)analog output voltage: ±10V min; (5)analog outout current: 3mA; (6)analog output short circuit current: 20mA; (7)analog output impedance: 1Ω; (8)aperture time: 30ns; (9)aperture uncertainty: 0.4ns; (10)offset step (pedestal): ±2mV; (11)operating temperature range: 0 to 70℃; (12)storage temeprature range: -55 to 125℃.

Features

AD389KD features: (1)companion to high resolution A/D converters; (2)fast acquisition time: 2.5μs to ±0.003%; (3)low droop rate: 0.1μV/μs; (4)aperture jitter: 400ps; (5)internal hold capacitor; (6)unity gain inverter; (7)low power dissipation: 300mW.

Diagrams

AD389KD functional block diagram
