A3952SLBTR

SOP, full-bridge, PWM motor driver, 50 V, ±3.5 A, -0.3 V to VCC + 0.3 V, Current-Decay Mode, Crossover-Current Protection

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: A3952SLBTR

Brand:: Allegro MicroSystems - Allegro | Pack: SOP | D/C: 03+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Cherry's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-02

From Other Seller

Part Number:A3952SLBTR
US $1.00 - 2.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The A3952SLBTR is the full-bridge PWM motor driver, which is designed for bidirectional pulse-width modulated current control of inductive loads. Internal circuit protection of the A3952SLBTR includes thermal shutdown with hysteresis, transient suppression diodes, and crossovercurrent protection. Special power-up sequencing is not required. With the ENABLE input held low, the PHASE input controls load current polarity by selecting the appropriate source and sink driver pair. The MODE input determines whether the PWM current-control circuitry operates in a slow current-decay mode (only the selected sink driver switching) or in a fast current-decay mode (selected source and sink switching). The A3952SLBTR is supplied in a choice of four power packages.

Parametrics

A3952SLBTR absolute maximum ratings: (1)Load Supply Voltage: 50 V; (2)Output Current (tw ≤ 20 μs): ±3.5 A; (Continuous): ±2.0 A; (3)Logic Supply Voltage: 7.0 V; (4)Logic Input Voltage Range: -0.3 V to VCC + 0.3 V; (5)Sense Voltage: 1.5 V; (6)Reference Voltage: 15 V; (7)Package Power Dissipation: See Graph; (8)Operating Temperature Range: –20 to +85℃; (9)Junction Temperature: +150℃; (10)Storage Temperature Range: –55 to +150℃.

Features

A3952SLBTR features: (1)±2 A Continuous Output Current Rating; (2)50 V Output Voltage Rating; (3)Internal PWM Current Control; (4)Fast and Slow Current-Decay Modes; (5)Sleep (Low Current Consumption) Mode; (6)Internal Transient Suppression Diodes; (7)Under-Voltage Lockout; (8)Internal Thermal Shutdown Circuitry; (9)Crossover-Current Protection.
