Product Summary
The BDG1A16G-1R is a quad differential driver, which is TTL input-topseudo-ECL-differential-output used for digital data transmission over balanced transmission lines. It has four drivers with a single enable control in a common package. The BDG1A16G-1R is compatible with many receivers, including the Agere Systems Inc. 41 Series receivers and transceivers.
Parametrics
BDG1A16G-1R absolute maximum ratings: (1)Power Supply Voltage: 6.5 V; (2)Ambient Operating Temperature: -40 to 125 ℃; (3)Storage Temperature: -55 to 150 ℃.
Features
BDG1A16G-1R features: (1)Pin-equivalent to the general-trade 26LS31 device, with improved speed, reduced power consumption, and significantly lower levels of EMI; (2)Four line drivers per package; (3)Meets ESDI standards; (4)2.0 ns maximum propagation delay; (5)Single 5.0 V ± 10% supply; (6)Operating temperature range: -40 ℃ to +125 ℃ (wider than the 41 Series); (7)400 Mbits/s maximum data rate.
Diagrams
 |
